PV SUN COVER 56/30/21

Photovoltaics

Item No. 8000087025

Properties

General ordering data

Version	Photovoltaics
Order No.	8000087025
Type	PV SUN COVER 56/30/21
GTIN (EAN)	4064675845188
Qty.	1 items

Dimensions and weights

Depth	326 mm
Depth (inches)	12.835 inch
Height	341 mm
Height (inches)	13.425 inch
Width	629 mm
Width (inches)	24.764 inch
Net weight	5,200 g

Environmental Product Compliance

RoHS Compliance Status	Compliant without exemption
REACH SVHC	No SVHC above 0.1 wt%

Material

Stainless steel 1.4301 (304)

Downloads

Engineering Data	[CAD data -- STEP](https://mdcop.weidmueller.com/mediadelivery/asset/900_252897) [Application notes -- Positions of attachment holes](https://mdcop.weidmueller.com/mediadelivery/asset/900_257094)
CADENAS eCATALOG	[CAX data](https://weidmueller-embedded.partcommunity.com?catalog=weidmueller_qs&part=8000087025)
Technical Documentation	[Temporary picture for PV Sun Covers](https://mdcop.weidmueller.com/mediadelivery/asset/900_255394)
Catalogues	[Catalogues in PDF-format](LINK/Catalog.html)

Classifications

ETIM 6.0	EC002498
ETIM 7.0	EC002498
ETIM 8.0	EC002498
ETIM 9.0	EC002498
ECLASS 9.0	27-37-92-01
ECLASS 9.1	27-18-92-90
ECLASS 10.0	27-37-13-92
ECLASS 11.0	27-37-13-92
ECLASS 12.0	27-37-13-92
ECLASS 13.0	27-37-13-92
ECLASS 14.0	27-37-13-92

Approvals

ROHS

Conform
