Properties
| Order No. | 6720000788 |
| Type | RS PLC IPC-620 22-POINTS |
| GTIN (EAN) | 4050118485806 |
| Qty. | 1 items |
| Depth | 61 mm |
| Depth (inches) | 2.402 inch |
| Height | 266 mm |
| Height (inches) | 10.472 inch |
| Width | 29 mm |
| Width (inches) | 1.142 inch |
| Net weight | 40 g |
| Storage temperature | 0...50 °C |
| Operating temperature | 0...50 °C |
| REACH SVHC | Lead 7439-92-1 |
| SCIP | 3820ceea-2b49-4a61-bda5-08f3867b3419 |
| Operating voltage | 150 V |
| Max. current per channel | 5 A |
| Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
| ETIM 6.0 | EC002780 |
| ETIM 7.0 | EC002780 |
| ETIM 8.0 | EC002780 |
| ETIM 9.0 | EC002780 |
| ECLASS 9.0 | 27-14-11-52 |
| ECLASS 9.1 | 27-24-22-92 |
| ECLASS 10.0 | 27-14-11-52 |
| ECLASS 11.0 | 27-14-11-52 |
| ECLASS 12.0 | 27-14-11-52 |
| ECLASS 13.0 | 27-14-11-52 |
| Approvals |  |
| ROHS | Conform |
