Properties
| Version | Hood version Ex, M12, 30 V, A-coded, LED: No, LED initiator: No, Wiring type: PNP |
| Order No. | 2943810000 |
| Type | SAI-04D-VPPP-5A-M12O-OL2-EX |
| GTIN (EAN) | 4099986729988 |
| Qty. | 1 items |
| Depth | 60 mm |
| Depth (inches) | 2.362 inch |
| Height | 41.5 mm |
| Height (inches) | 1.634 inch |
| Length | 102 mm |
| Length (inches) | 4.016 inch |
| Net weight | 225 g |
| Operating temperature | -40 - 60°C |
| RoHS Compliance Status | Compliant without exemption |
| REACH SVHC | No SVHC above 0.1 wt% |
| Wire connection method | PUSH IN |
| Cable glands | M 20 |
| Clamping range, min. | 0.14 mm² |
| Clamping range, max. | 1.5 mm² |
| Distributor outlet | Hood version Ex |
| Rated voltage, min. | 0 V |
| Rated voltage, max. | 30 V |
| Max. current-carrying capacity per slot | 0.8 A |
| Total current | 0.8 A |
| Current per signal | 0.8 A |
| Plug-in station coding | A-coded |
| Protection degree |
IP66
IP67 |
| Surge voltage category | III |
| Number of poles | 5 |
| Number of contact sockets | 4 |
| Connection thread | M12 |
| Pollution severity | 3 |
| Fire behaviour | V-0 |
| Plugging cycles | ≤ 50 |
| LED | No |
| LED initiator | No |
| Material O-Ring | FKM |
| Housing main material | Pocan |
| Housing colour | black (similar to RAL 9005) |
| Hood sealing material | Polyurethane foamed |
| Screw socket | Nickel-plated CuZn |
| Contact material | CuZn |
| Contact surface | Gold-plated |
| Contact carrier material | PBT (UL 94 V0) |
| Cable gland material | Plastic |
| Product information |
Included in delivery:
|
| Approval/Certificate/Document of Conformity |
[IECEx Certificate](https://mdcop.weidmueller.com/mediadelivery/asset/900_315581)
[ATEX Certificate](https://mdcop.weidmueller.com/mediadelivery/asset/900_315582) [CE Declaration of Conformity](https://mdcop.weidmueller.com/mediadelivery/asset/900_315583) |
| Engineering Data | [CAD data -- STEP](https://mdcop.weidmueller.com/mediadelivery/asset/900_317382) |
| CADENAS eCATALOG | [CAX data](https://weidmueller-embedded.partcommunity.com?catalog=weidmueller_qs&part=2943810000) |
| Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
| ETIM 6.0 | EC002585 |
| ETIM 7.0 | EC003558 |
| ETIM 8.0 | EC003558 |
| ETIM 9.0 | EC003558 |
| ECLASS 9.0 | 27-44-01-08 |
| ECLASS 9.1 | 27-44-01-08 |
| ECLASS 10.0 | 27-44-01-11 |
| ECLASS 11.0 | 27-44-01-11 |
| ECLASS 12.0 | 27-44-01-11 |
| ECLASS 13.0 | 27-44-01-11 |
| ECLASS 14.0 | 27-44-01-11 |
| Approvals |    |
