Properties
| Version | RIDERSERIES RCL, Retaining clip |
| Order No. | 8691090000 |
| Type | SRC CLIP LP |
| GTIN (EAN) | 4032248361793 |
| Qty. | 10 items |
| Net weight | 1.97 g |
| Storage temperature | -40 °C...85 °C |
| Operating temperature | -40 °C...70 °C |
| Humidity | 40 °C / 93 % rel. humidity, no condensation |
| RoHS Compliance Status | Compliant without exemption |
| REACH SVHC | No SVHC above 0.1 wt% |
| Version | for low relays |
| Material | Plastic |
| Colour | black |
| Protection degree | IP20 |
| Eplan Data Portal | [Eplan data](https://dataportal.eplan.com/part-details/WEI.8691090000) |
| Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
| ETIM 6.0 | EC002586 |
| ETIM 7.0 | EC002586 |
| ETIM 8.0 | EC002586 |
| ETIM 9.0 | EC002586 |
| ECLASS 9.1 | 27-37-16-92 |
| ECLASS 10.0 | 27-37-16-92 |
| ECLASS 11.0 | 27-37-16-92 |
| ECLASS 12.0 | 27-37-16-92 |
| ECLASS 13.0 | 27-37-16-92 |
| ECLASS 14.0 | 27-37-16-92 |
| ROHS | Conform |
