Properties
| Order No. | 2938270000 |
| Type | WBC-CH-6OR-BK-25-0023 |
| GTIN (EAN) | 4099986699120 |
| Qty. | 1 items |
| Length | 324 mm |
| Length (inches) | 12.756 inch |
| Net weight | 120 g |
| Continuous operating temp., min. | -40 °C |
| Continuous operating temp., max. | 125 °C |
| Approvals | UL 4128 |
| Colour |
black
orange |
| Conductor cross-section, max. | 25 mm² |
| Contact diameter, male Ø | 6 mm |
| Material | PA 66 |
| Outer cable diameter, max. | 6 mm |
| Surface finish | silver |
| Type | Female |
| Type of connection | Crimp connection |
| Length | 324 mm |
| Plugging cycles | ≥ 100 |
| Protection degree | IP67 plugged |
| Rated current | 120 A |
| Rated voltage | 1,500 V |
| UL 94 flammability rating | V-0 |
| Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
| ETIM 7.0 | EC001121 |
| ETIM 8.0 | EC001121 |
| ETIM 9.0 | EC001121 |
| ECLASS 10.0 | 27-44-03-12 |
| ECLASS 11.0 | 27-44-03-12 |
| ECLASS 12.0 | 27-44-03-12 |
| ECLASS 13.0 | 27-44-03-12 |
| ROHS | Conform |
