Ominaisuudet
| Version | Insert, PROFINET, Socket connector |
| Order No. | 1068940000 |
| Type | IE-BID-24V |
| GTIN (EAN) | 4032248823086 |
| Qty. | 100 items |
| Height | 13,5 mm |
| Height (inches) | 0,531 inch |
| Width | 27,4 mm |
| Width (inches) | 1,079 inch |
| Length | 13,1 mm |
| Length (inches) | 0,516 inch |
| Net weight | 2,6 g |
| Operating temperature | -40 °C...70 °C |
| Contact material | Cu-alloy |
| Contact surface | Gold over nickel |
| Number of poles | 5 |
| Plugging cycles | ≤ 100 |
| Shielding | unshielded |
| Current-carrying capacity at 50 °C | 16 A |
| Operating voltage | 24 V |
| Connector standard | IEC 61076-3-126 |
| Connector standard | IEC 61076-3-126 |
| Engineering Data | [CAD data -- STEP](https://mdcop.weidmueller.com/mediadelivery/asset/900_46966) |
| CADENAS eCATALOG | [CAX data](https://weidmueller-embedded.partcommunity.com?catalog=weidmueller_qs&part=1068940000) |
| WSCAD Universe | [WSCAD data](https://wscaduniverse.com/part-detail?manufacturerId=88&type=0&partNumber=1068940000&norm=0) |
| User Documentation |
[MAN IE GUIDE DE](https://mdcop.weidmueller.com/mediadelivery/asset/900_40065)
[MAN IE GUIDE EN](https://mdcop.weidmueller.com/mediadelivery/asset/900_40066) |
| Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
| Brochures |
[MB FREECONCONTACT EN](http://download.weidmueller.com/asset/download/file/38173)
[FL FIELDWIRING EN](http://download.weidmueller.com/asset/download/file/38293) [PI PROFINET CABLING EN](http://download.weidmueller.com/asset/download/file/38183) |
| ETIM 6.0 | EC001121 |
| ETIM 7.0 | EC001121 |
| ETIM 8.0 | EC001121 |
| ETIM 9.0 | EC001121 |
| ECLASS 9.0 | 27-44-03-90 |
| ECLASS 9.1 | 27-44-03-90 |
| ECLASS 10.0 | 27-44-03-90 |
| ECLASS 11.0 | 27-44-03-90 |
| ECLASS 12.0 | 27-44-03-90 |
| ECLASS 13.0 | 27-44-03-90 |
| ROHS | Conform |
