Ominaisuudet
| Version | Terminal rail fixing, Surge protection, 802.3 bt at Type 1, 802.3 bt at Type 2, 802.3 bt at Type 3, 802.3 bt at Type 4, Cat.5e |
| Order No. | 2916360000 |
| Type | VDATA CAT5E |
| GTIN (EAN) | 4099986545519 |
| Qty. | 1 items |
| Depth | 46 mm |
| Depth (inches) | 1,811 inch |
| Height | 75 mm |
| Height (inches) | 2,953 inch |
| Width | 19 mm |
| Width (inches) | 0,748 inch |
| Net weight | 118 g |
| Storage temperature | -40 °C...85 °C |
| Operating temperature | -40 °C...80 °C |
| Humidity | 0...95 % (no condensation) |
| RoHS Compliance Status | Compliant without exemption |
| REACH SVHC | No SVHC above 0.1 wt% |
| Colour | Silver grey |
| Design |
miscellaneous
Adapter plug |
| Operating altitude | ≤ 2000 m |
| Protection degree | IP20 |
| Rail |
TS 35 x 15
TS 35 x 7.5 |
| Segment | Data surge protection |
| Version |
802.3 bt at Type 1
802.3 bt at Type 2 802.3 bt at Type 3 802.3 bt at Type 4 Cat.5e |
| Pollution severity | 2 |
| Surge voltage category | III |
| Discharge current Imax (8/20µs) wire-PE | 10 kA |
| Discharge current In (8/20µs) wire-PE | 10 kA |
| Discharge current In (8/20µs) wire-wire | 1.5 kA |
| Discharge current, Iimp (10/350 µs) | 1 kA |
| Frequency range, max. | 100 MHz |
| Lightning test current, Iimp (10/350 µs) Wire-PE | 1 kA |
| Max. continuous voltage, Uc (AC) | 48 V |
| Max. continuous voltage, Uc (DC) | 72 V |
| Protection level, UP wire - PE | 550 V |
| Protection level, UP wire - wire | 600 V |
| Rated current IN | 1 A |
| Rated voltage (DC) | 48 V |
| Requirements category acc. to IEC 61643-21 |
D1
C1 C2 C3 |
| Response time | <1 ns |
| Standards | IEC 61643-21 |
| Surge current-carrying capacity C2 | 10 kA |
| Surge current-carrying capacity D1 | 1 kA 10/350 μs |
| Voltage type | AC/DC |
| Volume resistance | <0.1 Ω |
| Wire-PE capacitance @ 1 MHz, 1 Vrms | 20 pF |
| Wire-wire capacitance @ 1 MHz, 1 Vrms | 30 pF |
| Type of connection | RJ45-Port |
| Voltage type | AC/DC |
| Protection degree | IP20 |
| Colour | Silver grey |
| Time interval | 5 years |
| Approval/Certificate/Document of Conformity | [EU_Konformitätserklärung / EU_Declaration_of_Conformity](https://mdcop.weidmueller.com/mediadelivery/asset/900_298629) |
| User Documentation | [Beipackzettel / Instruction sheet](https://mdcop.weidmueller.com/mediadelivery/asset/900_38520) |
| Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
| ETIM 6.0 | EC000943 |
| ETIM 7.0 | EC000943 |
| ETIM 8.0 | EC000943 |
| ETIM 9.0 | EC000943 |
| ECLASS 9.0 | 27-13-08-07 |
| ECLASS 9.1 | 27-13-08-07 |
| ECLASS 10.0 | 27-13-08-07 |
| ECLASS 11.0 | 27-13-08-07 |
| ECLASS 12.0 | 27-17-90-90 |
| ECLASS 13.0 | 27-17-90-90 |
| ECLASS 14.0 | 27-17-90-90 |
| ROHS | Conform |
