Propriétés
| Version | Connecteur capteur/actionneur, Insert |
| Référence | 1995810000 |
| Type | SAI-M23-BE-L-4/4 |
| GTIN (EAN) | 4032248925674 |
| Qté. | 1 Pièce |
| Poids net | 10 g |
| Statut de conformité RoHS | Conforme sans exemption |
| REACH SVHC | No SVHC above 0.1 wt% |
| Codage | aucune |
| Courant nominal |
Contact 1 mm = 8 A
Contact 2 mm = 28 A |
| Cycles d'enfichage | > 1000 |
| Degré de pollution | 3 |
| Matériau de base du boîtier | Polyamide thermoplastique PA 6, PBT |
| Nombre de pôles | 8 |
| Type de raccordement | Raccordement à sertir |
| Données techniques | [CAD data -- STEP](https://mdcop.weidmueller.com/mediadelivery/asset/900_188602) |
| CADENAS eCATALOG | [CAX data](https://weidmueller-embedded.partcommunity.com?catalog=weidmueller_qs&part=1995810000) |
| Catalogue | [Catalogues in PDF-format](LINK/Catalog.html) |
| Brochures |
[FL FIELDWIRING EN](http://download.weidmueller.com/asset/download/file/38293)
[FL FIELDWIRING EN](http://download.weidmueller.com/asset/download/file/38293) |
| ETIM 6.0 | EC000438 |
| ETIM 7.0 | EC003557 |
| ETIM 8.0 | EC003557 |
| ETIM 9.0 | EC003557 |
| ECLASS 9.1 | 27-44-02-05 |
| ECLASS 10.0 | 27-44-02-23 |
| ECLASS 11.0 | 27-44-02-23 |
| ECLASS 12.0 | 27-44-02-23 |
| ECLASS 13.0 | 27-44-02-23 |
| ECLASS 14.0 | 27-44-02-23 |
| Agréments |    |
| ROHS | Conforme |
| UL File Number Search | [Site Web UL](LINK/UL_search.html) |
| Certificat Nº (UR) | E344862 |
