IE-C5ES8VB0025N40N40-B-K6KV

Patch cable, RJ45 IP30 (plugged), RJ45 IP30 (plugged), Cat.5 (ISO/IEC 11801) / Cat.5e (TIA T568-B), PVC, 2.5 m, , straight, 6 kV

Product ID 2813820025
Gegevensblad downloaden Engineering Support Product Downloads
Verwante producten 10
General ordering data Dimensions and weights Temperatures Environmental Product Compliance Electrical properties General standards Standards Cable structure Electrical properties of cable Mechanical and material properties of cable Plug Plug, left Plug, right Classifications Approvals

General ordering data

Version
Patch cable, RJ45 IP30 (plugged), RJ45 IP30 (plugged), Cat.5 (ISO/IEC 11801) / Cat.5e (TIA T568-B), PVC, 2.5 m, , straight, 6 kV
Order No.
2813820025
Type
IE-C5ES8VB0025N40N40-B-K6KV
GTIN (EAN)
4064675298359
Qty.
1  items

Dimensions and weights

Length
2,5  m
Length (inches)
98,425  inch
Net weight
102  g

Temperatures

Operating temperature
-20 °C...70 °C
Installation temperature
0 °C...50 °C

Environmental Product Compliance

RoHS Compliance Status
Compliant
REACH SVHC
No SVHC above 0.1 wt%

Electrical properties

Operating voltage
125  V
PoE / PoE+
conforming to IEEE 802.3at

General standards

Connector standard
IEC 60603-7-51

Standards

Connector standard
IEC 60603-7-51

Cable structure

Cable layout
Double insulation according to VDE 0603-100
Colour coding
white / blue
white / orange
white / green
white / brown
Complete shielding
Shielding braid made from copper wiring
Aluminium foil
Cross-section
4x2xAWG 26/7. 4x2x0.128 mm²
Insulation
PE
Insulation cross-section
1  mm
Material sheath
PVC
Number of wires
8
Sheath diameter
5.5 mm
Sheathing colour
blue
Shielding
SF/UTP

Electrical properties of cable

Category
Cat.5 (ISO/IEC 11801) / Cat.5e (TIA T568-B)
Operating voltage
125  V
Rated impulse withstand voltage
6 kV
Signal propagation time
5,1  ns/m

Mechanical and material properties of cable

Bending radius
4 x cable diameter
Colour
blue (RAL 5015)
Min. bending radius, once only
5 x cable diameter
Resistance to spread of flame
in accordance with IEC 60332-1-2

Plug

Plug left
RJ45, IP30 (plugged), male contact, straight, plug, shielded
Plug right
RJ45, IP30 (plugged), male contact, straight, plug, shielded

Plug, left

Plug left
RJ45, IP30 (plugged), male contact, straight, plug, shielded

Plug, right

Plug right
RJ45, IP30 (plugged), male contact, straight, plug, shielded

Classifications

ETIM 6.0
EC002599
ETIM 7.0
EC002599
ETIM 8.0
EC002599
ETIM 9.0
EC002599
ETIM 10.0
EC002599
ECLASS 9.0
27-06-03-08
ECLASS 9.1
27-06-03-08
ECLASS 10.0
27-06-03-08
ECLASS 11.0
27-06-03-08
ECLASS 12.0
27-06-03-08
ECLASS 13.0
27-06-03-08
ECLASS 14.0
27-06-03-08
ECLASS 15.0
27-06-03-08

Approvals

Approvals
![](https://mdcop.weidmueller.com/mediadelivery/rendition/900_319222/-S800/-T1z1mm-S80)
ROHS
Conform
