Özellikler
Version | Junction box, IP67, Variant 5, 2 ports, straight |
Order No. | 1966290000 |
Type | IE-OM-V05M-K21-2S |
GTIN (EAN) | 4032248658480 |
Qty. | 1 adet |
Depth | 57 mm |
Depth (inches) | 2,244 inch |
Width | 136 mm |
Width (inches) | 5,354 inch |
Length | 125 mm |
Length (inches) | 4,921 inch |
Net weight | 643 g |
Operating temperature | -40 °C...70 °C |
RoHS Compliance Status | Compliant with exemption |
RoHS Exemption (if applicable/known) | 6bI, 6c |
REACH SVHC |
Lead 7439-92-1
Potassium perfluorobutane sulfonate 29420-49-3 |
SCIP | 3767b26f-703a-492e-9234-36e83d1c0725 |
Colour | grey |
Housing main material | AL-Si 12 |
Plugging cycles | 750 |
Protection degree | IP67 |
Type of mounting |
Floor-mounted
Wall mounting |
Connector standard | IEC 61076-3-106 Var. 5 |
Approval/Certificate/Document of Conformity | [GOST Approval](https://mdcop.weidmueller.com/mediadelivery/asset/900_58423) |
Engineering Data | [CAD data -- STEP](https://mdcop.weidmueller.com/mediadelivery/asset/900_246633) |
CADENAS eCATALOG | [CAX data](https://weidmueller-embedded.partcommunity.com?catalog=weidmueller_qs&part=1966290000) |
User Documentation |
[MAN IE GUIDE DE](https://mdcop.weidmueller.com/mediadelivery/asset/900_40065)
[MAN IE GUIDE EN](https://mdcop.weidmueller.com/mediadelivery/asset/900_40066) |
Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
Brochures |
[MB FREECONCONTACT EN](http://download.weidmueller.com/asset/download/file/38173)
[FL FIELDWIRING EN](http://download.weidmueller.com/asset/download/file/38293) [PI PROFINET CABLING EN](http://download.weidmueller.com/asset/download/file/38183) [PI PROFINET CABLING EN](http://download.weidmueller.com/asset/download/file/38183) |
ETIM 7.0 | EC002597 |
ETIM 8.0 | EC002597 |
ETIM 9.0 | EC002597 |
ECLASS 9.1 | 27-44-03-18 |
ECLASS 10.0 | 27-44-03-18 |
ECLASS 11.0 | 27-44-03-18 |
ECLASS 12.0 | 27-44-03-18 |
ECLASS 13.0 | 27-44-03-18 |
ECLASS 14.0 | 27-44-03-18 |
ROHS | Conform |
Aksesuarlar
-
Ürün No.:1077300000Ambalaj birimi:10 adet
RJ45 plug, no tools required, Cat.6A / Class EA (ISO/IEC 11801 2010)
-
Ürün No.:1963200000Ambalaj birimi:10 adet
RJ45 plug, no tools required, Variant 5, Cat.6A / Class EA (ISO/IEC 11801 2010)
-
Ürün No.:1963110000Ambalaj birimi:10 adet
RJ45 crimp plug, Variant 5, Cat.6A / Class EA (ISO/IEC 11801 2010)
-
Ürün No.:1963840000Ambalaj birimi:10 adet
RJ45 insert socket, Connector for base, TIA-568B
-
Ürün No.:1963830000Ambalaj birimi:10 adet
RJ45 insert socket, Connector for base, PROFINET
-
Ürün No.:1962850000Ambalaj birimi:10 adet
RJ45 insert socket, Connector for base, TIA-568A
