Egenskaber
| Version | Built-in plugs, M8 snap, pin, straight, Mounting thread: M8, Number of poles: 4, Strand / cable length: 0.5 m |
| Order No. | 1861290000 |
| Type | SAIE-M8R-4-0.5U-FP-M8 |
| GTIN (EAN) | 4032248419364 |
| Qty. | 1 Styk |
| Net weight | 14 g |
| RoHS Compliance Status | Compliant |
| REACH SVHC | Lead 7439-92-1 |
| SCIP | ebf89fc8-a87f-4691-b87a-dfb9921774b4 |
| Cable glands | M 8 |
| Contact surface | Gold-plated |
| Housing main material |
Brass
nickel-plated |
| Number of poles | 4 |
| Plugging cycles | ≥ 100 |
| Protection degree |
IP67
when screwed in |
| Rated current | 4 A |
| Rated voltage | 30 V |
| Temperature range of housing | -30…+90 °C |
| Type of connection | Pin |
| Cable glands | M 8 |
| Cable length | 0,5 m |
| Conductor O.D. | - |
| Connection thread | M8 snap |
| Contact surface | Gold-plated |
| Core cross-section | 0,25 mm² |
| Housing main material |
Brass
nickel-plated |
| Material | PVC |
| Mounting thread | M8 |
| Number of poles | 4 |
| Plugging cycles | ≥ 100 |
| Protection degree |
IP67
when screwed in |
| Rated current | 4 A |
| Rated voltage | 30 V |
| Rated voltage | 60 V (3-pole) / 30 V (4-pole) |
| Strand / cable length | 0,5 m |
| Temperature range of housing | -30…+90 °C |
| Type of connection | Pin |
| Engineering Data | [CAD data -- STEP](https://mdcop.weidmueller.com/mediadelivery/asset/900_181302) |
| CADENAS eCATALOG | [CAX data](https://weidmueller-embedded.partcommunity.com?catalog=weidmueller_qs&part=1861290000) |
| Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
| Brochures |
[FL FIELDWIRING EN](http://download.weidmueller.com/asset/download/file/38293)
[FL FIELDWIRING EN](http://download.weidmueller.com/asset/download/file/38293) |
| ETIM 6.0 | EC002635 |
| ETIM 7.0 | EC003570 |
| ETIM 8.0 | EC003570 |
| ETIM 9.0 | EC003570 |
| ECLASS 9.0 | 27-44-01-03 |
| ECLASS 9.1 | 27-44-01-03 |
| ECLASS 10.0 | 27-44-01-03 |
| ECLASS 11.0 | 27-44-01-03 |
| ECLASS 12.0 | 27-44-01-03 |
| ECLASS 13.0 | 27-44-01-03 |
| ECLASS 14.0 | 27-44-01-03 |
| Approvals |  |
| ROHS | Conform |
| UL File Number Search | [UL Website](LINK/UL_search.html) |
| Certificate no. (cULus) | E307231 |
