Eigenschappen
| Version | Built-in plugs, 7/8", Mounting thread: PG 13.5, Number of poles: 4, Strand / cable length: 0.2 m |
| Order No. | 1292440000 |
| Type | SAIE-7/8B-4-0.2U-PG13.5 |
| GTIN (EAN) | 4050118088458 |
| Qty. | 1 items |
| Net weight | 43 g |
| RoHS Compliance Status | Compliant |
| REACH SVHC | Lead 7439-92-1 |
| SCIP | ebf89fc8-a87f-4691-b87a-dfb9921774b4 |
| Cable glands | PG 13.5 |
| Coding | none |
| Contact material | CuZn |
| Contact surface | Gold-plated |
| Housing main material |
Zinc diecast
nickel-plated |
| Number of poles | 4 |
| Plugging cycles | ≥ 100 |
| Protection degree |
IP67
when screwed in |
| Rated current | 8 A |
| Rated current | 8 A (4- and 5-pole), 10 A (3-pole) |
| Rated voltage | 300 V |
| Temperature range of housing | -25…+85 °C |
| Type of connection | Socket connector |
| Cable glands | PG 13.5 |
| Cable length | 0,2 m |
| Coding | none |
| Conductor O.D. | - |
| Connection thread | 7/8" |
| Contact material | CuZn |
| Contact surface | Gold-plated |
| Core cross-section | 0,75 mm² |
| Housing main material |
Zinc diecast
nickel-plated |
| Material | PUR/ PUR |
| Mounting thread | PG 13.5 |
| Mounting torque |
|
| Mounting torque range | 6 ... 6.25 Nm |
| Number of poles | 4 |
| Plugging cycles | ≥ 100 |
| Protection degree |
IP67
when screwed in |
| Rated current | 8 A |
| Rated current | 8 A (4- and 5-pole), 10 A (3-pole) |
| Rated impulse voltage | 4.000 V |
| Rated voltage | 300 V |
| Rated voltage | 300 V |
| Rated voltage (UL) | 600 V |
| Strand / cable length | 0,2 m |
| Temperature range of housing | -25…+85 °C |
| Tightening torque | 1,5 Nm |
| Type of connection | Socket connector |
| Catalogues | [Catalogues in PDF-format](LINK/Catalog.html) |
| Brochures |
[FL FIELDWIRING EN](http://download.weidmueller.com/asset/download/file/38293)
[FL FIELDWIRING EN](http://download.weidmueller.com/asset/download/file/38293) |
| ETIM 6.0 | EC002635 |
| ETIM 7.0 | EC003570 |
| ETIM 8.0 | EC003570 |
| ETIM 9.0 | EC003570 |
| ECLASS 9.0 | 27-44-01-03 |
| ECLASS 9.1 | 27-44-01-03 |
| ECLASS 10.0 | 27-44-01-03 |
| ECLASS 11.0 | 27-44-01-03 |
| ECLASS 12.0 | 27-44-01-03 |
| ECLASS 13.0 | 27-44-01-03 |
| ECLASS 14.0 | 27-44-01-03 |
| Approvals |  |
| ROHS | Conform |
| UL File Number Search | [UL Website](LINK/UL_search.html) |
| Certificate No. (cURus) | E307231 |
